Boikanyo Sheets and Plates, located in Cape Town, South Africa, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Duplex Steel Sheet and Plates S31803. Known for their precision engineering and high product standards, this company provides durable solutions that cater to the diverse needs of industries around the globe. With a strong emphasis on innovation and dependability, Boikanyo guarantees that its Duplex Steel Sheets and Plates adhere to strict quality standards for various applications. By blending technical know-how with a customer-focused approach, they have built a strong reputation for delivering premium-grade steel products that promise strength, corrosion resistance, and long-lasting performance.
The Duplex Steel Sheet and Plates S31803 are primarily made up of 22% chromium, 5–6% nickel, and 3% molybdenum, with nitrogen playing a key role in boosting strength and corrosion resistance. This well-balanced composition provides exceptional resistance to pitting, stress corrosion cracking, and crevice corrosion, especially when compared to standard stainless steels. On the mechanical side, S31803 duplex steel boasts impressive tensile strength (around 620 MPa), excellent yield strength (at least 450 MPa), and good elongation, merging the toughness of austenitic steel with the hardness of ferritic grades. Its unique dual-phase microstructure ensures durability, stability, and outstanding performance even in tough industrial settings.
| Size | : | 1/2″NB TO 4″NB IN |
| Standard | : | ASTM A182 / ASME SA182 |
| Dimensions | : | ANSI/ASME B16.11 & BS3799, etc. |
| Grade | : | UNS S31803, S32205, S2205, S32550, S32750, S32760. |
| Class | : | 2000LBS, 3000LBS, 6000LBS, 9000LBS, etc. |
| UNS S31803 | Ni | Cr | Mo | Mn | Si | C | N | S | P | Fe |
| min | 4.5 | 22.0 | 3.0 | – | – | – | 0.14 | – | – | – |
| max | 6.5 | 23.0 | 3.5 | 2.0 | 1.0 | 0.03 | 0.2 | 0.02 | 0.03 | Balance |
| Grade | S31803 |
| Density (g/cm 3) | 7.805 |
| Density (lb/in 3) | 0.285 |
| Melting Point (°C) | 1420 – 1465 |
| Melting Point (°F) | 2588 – 2669; |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Duplex Steel Sheet and Plates S31803 offer exceptional strength, corrosion resistance, and durability, making them ideal for harsh environments. With a balanced microstructure of austenite and ferrite, they provide higher resistance to stress corrosion cracking and pitting. These plates are highly resistant to chloride environments, ensuring long-lasting performance in industries like oil and gas, chemical processing, and marine applications. Their excellent weldability and formability make them versatile for various fabrication processes, while their cost-effectiveness compared to high-alloy steels makes them a popular choice for demanding applications.
| Duplex 2205 | UNS S31803 | 1.4462 | F51 |
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
Duplex Steel Sheet and Plates S31803 find their way into various industries where high strength and excellent corrosion resistance are essential. They are commonly used in chemical processing, marine applications, and oil and gas exploration, particularly in equipment that faces harsh, chloride-rich environments. These sheets and plates are perfect for heat exchangers, pressure vessels, storage tanks, and structural components in desalination plants. Additionally, they are utilized in the pulp and paper industry, as well as in architecture and construction projects that demand durable and cost-effective materials. Their remarkable mechanical properties and corrosion resistance make them a trusted choice for many applications.
